Yamaha F400A 2022 - Intake Manifold

Intake manifold
6-24
Intake manifold
New
25
26
29
28
37
7
16
17
21
10
3
4
11
A
5
4
24
22
31
27
New
8
New
7
New
6
15
13
15
14
New
29
New
23
New
New
20
New
19New
7
New
7
New
9
16
17
18
7
New
1
2
New
New
12
1
38
36
29
39
35
30
32
33
New
29
34
24 N
·
m (2.4 kgf
·
m, 18 lb
·ft
)
11 N
·
m (1.1 kgf
·
m, 8.1 lb
·ft
)
Part name
Q
’ty
Remarks
1 Plastic tie 2
2 Plastic tie 1
3 Oil dipstick 1
4Bolt M6
× 16 mm 3
5 Dipstick guide 1
6O-ring 1
7 Plastic tie 6
8 Plastic tie 1
9Hose 1
10 Hose 1
11 Joint 1
12 Hose 1
13 Bolt M6
× 12 mm 2
14 Bracket 1
15 Holder 2
16 Bolt M8
× 35 mm 10
17 Bolt M6
× 40 mm 10
18
Intake manifold
(PORT)
1
19 Gasket 1
20 Gasket 1
21
Intake manifold
(STBD)
1
22 Gasket 1
23 Gasket 1
24 Holder 2
25 Plastic tie 1
26 Holder 1
27 Holder 1
28 Holder 2
29 Plastic tie 12
30 Hose 1
31 Hose 1
32 Joint 1
33 Hose 1
34 Hose 1
35 Joint 1
36 Hose 1
Part name
Q
’ty
Remarks
