Yamaha F400A 2022 - Oil Cooler and Water Jacket

7-72
Oil cooler and water jacket
Oil cooler and water jacket
3.9 N
·
m (0.39 kgf
·
m, 2.9 lb
·ft
)
3.9 N
·
m (0.39 kgf
·
m, 2.9 lb
·ft
)
6 N
·
m (0.6 kgf
·
m, 4.4 lb
·ft
)
10 N
·
m (1.0 kgf
·
m, 7.4 lb
·ft
)
1
2
6 N
·
m (0.6 kgf
·
m, 4.4 lb
·ft
)
10 N
·
m (1.0 kgf
·
m, 7.4 lb
·ft
)
1
2
6 N
·
m (0.6 kgf
·
m, 4.4 lb
·ft
)
10 N
·
m (1.0 kgf
·
m, 7.4 lb
·ft
)
1
2
1
5
16
17
7
8
1
2
1
13
12
14
16
17
1
1
10
6
New
9
11
New
15
New
New
4
3
18
20
20
19
18
New
21
New
21
New
19
3
8
242242
LTLT
242242
LTLT
EE
EE
EE
Part name
Q
’ty
Remarks
1Bolt M6
× 25 mm 32
2 Thermostat cover 1
3 Thermostat 1
4Gasket 1
5Cover 1
6Gasket 1
7 Thermostat cover 1
8 Thermostat 1
9Gasket 1
10 Cover 1
11 Gasket 1
12 Clamp 1
13 Hose 1
14 Cover 1
15 Gasket 1
16 Screw M6
× 25 mm 2
17 Anode 2
18 Bolt M6
× 40 mm 4
19 Thermostat cover 2
20 Thermostat 2
21 Gasket 2
Part name
Q
’ty
Remarks
