Yamaha F400A 2022 - Clamp Bracket and Swivel Bracket

9-42
Clamp bracket and swivel bracket
Clamp bracket and swivel bracket
3
3
4
4
5
1
1
2
6
6
7
6
6
8
12
9
9
10
10
10
11
23
9
24
24
15
14
16
13
16
19
21
21
21
22
22
19
20
17
18
25
17
20
21
20
17
271271
LTLT
241241
LTLT
271271
LTLT
AA
AA
AA
DD
DD
3.0 N
·
m (0.30 kgf
·
m, 2.2 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
3.0 N
·
m (0.30 kgf
·
m, 2.2 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
3.0 N
·
m (0.30 kgf
·
m, 2.2 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M6
× 10 mm 2
2 Ground lead 1
3Bolt M6
× 30 mm 4
4Plate 2
5Anode 1
6 Bushing 4
7 Clamp bracket (PORT) 1
8 Clamp bracket (STBD) 1
9 Grease nipple M6 5
10 Bolt M10
× 20 mm 4
11 Bracket (PORT) 1
12 Bracket (STBD) 1
13 Spring 1
14 Bolt M6
× 12 mm 1
15 Hook 1
16 Pin 2
17
Tilt support lever
(PORT)
1
18
Tilt support lever
(STBD)
1
19 Distance collar 2
20 Pin 1
21 Bushing 3
22 Nut M10 2
23 Trim stopper 2
24 Grommet 2
25 Swivel bracket 1
Part name
Q
’ty
Remarks
