Yamaha F400A 2022 - Steering Actuator and Steering Arm

9-32
Steering actuator and steering arm
Steering actuator and steering arm
*. Apply Valvoline X-ALL.
2
5
20
23
24
6
7
9
10
29
31
28
27
26
25
9
8
8
21
21
22
11
1
2
1
12
13
14
15
16
17
19
18
30
27
31
3
3
4
New
New
New
AA
AA
242242
LTLT
242242
LTLT
*
13 N
·
m (1.3 kgf
·
m, 9.6 lb
·ft
)
27 N
·
m (2.7 kgf
·
m, 20 lb
·ft
)
60 N
·
m (6.0 kgf
·
m, 44 lb
·ft
)
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
1
2
572572
LTLT
241241
LTLT
Part name
Q
’ty
Remarks
1Bolt M6
× 14 mm 6
2Cover 2
3Bolt M6
× 14 mm 4
4Cover 1
5 Cotter pin 1
6Nut M14 1
7Lever 1
8Bolt M8
× 35 mm 4
9Bolt M8
× 40 mm 8
10 Bracket (PORT) 1
11 Bracket (STBD) 1
12 Steering actuator 1
13 Bolt M6
× 18 mm 2
14 Holder 1
15 Bolt M4
× 10 mm 4
16 Cover 1
17 Bolt M8
× 8 mm 1
Positive ter-
minal
18 Bolt M6 × 8 mm 1
Negative ter-
minal
19 Lead 1
20 Plastic tie 1
21 Bolt M6
× 30 mm 2
22 Guide 1
23 Bolt M6
× 10mm 2
24 Ground lead 1
25 Circlip 1
26 Steering yoke 1
27 Washer 2
28 Washer 1
29 O-ring 1
30 Steering arm 1
31 Bushing 2
Part name
Q
’ty
Remarks
