Yamaha F400A 2022 - Starter Motor

5-45
Starter motor
Starter motor
6
13
14
15
4
22
21
17
19
23
20
16
10
7
8
12
5
3
11
24
2
9
18
1
New
New
CC
MM
Part name
Q
’ty
Remarks
1
Screw set M6
× 25
mm
2
2
Magnet switch assem-
bly
1
3Shim 1
Shim for pin-
ion gap ad-
justment
4Bolt M6
× 150 mm 2
5 Lever assembly 1
6 Pinion stopper set 1
7 Pinion set 1
8 Cover assembly 1
9 Center bracket 1
10
Ball 6.33 mm (0.25 in)
(reference data)
1
11
Starting motor gear
assembly
1
12 Stopper set 1
13 Clutch assembly 1
14 Bracket M4
× 16 mm 1
15
Pinion shaft M5
× 127
mm
1
16 Planetary gear 3
17 O-ring 1
18
Screw set M5
× 11
mm
1
19 Armature 1
20 Stator 1
21 O-ring 1
22 Bracket 1
23 Brush holder 1
24 Nut 1
Part name
Q
’ty
Remarks
