Yamaha F400A 2022 - Shift Actuator and Shift Rod

Shift actuator and shift rod
9-13
Shift actuator and shift rod
16
15
4
4
5
5
13
5
6
18
1
2
3
7
19
21
20
23
24
22
25
27
26
8
8
10
10
10
11
12
11
12
11
12
11
11
11
9
14
New
New
AA
AA
AA
AA
AA
AA
17
19 N
·
m (1.9 kgf
·
m, 14 lb
·ft
)
41 N
·
m (4.1 kgf
·
m, 30 lb
·ft
)
19 N
·
m (1.9 kgf
·
m, 14 lb
·ft
)
Part name
Q
’ty
Remarks
1Clip 1
2 Self-locking nut M6 1
3Washer 1
4Bolt M8
× 35 mm 3
5Washer 3
6 Bracket 1
7 Bushing 2
8Bolt M8
× 35 mm 3
9 Shift actuator 1
10 Collar 3
11 Grommet 6
12 Washer 3
13 Bushing 1
14 Cotter pin 1
15 Nut M10 1
16 Washer 1
17 Joint pin 1
18 Clip 1
19 Shift lever 1
20 Clip 1
21 Bolt M6
× 40 mm 2
22 SPS 1
23 Washer 1
24 Bushing 1
25 Shift rod 1
26 O-ring 1
27 Grommet 1
Part name
Q
’ty
Remarks
