Yamaha F400A 2022 - Cylinder Block Sensor

Cylinder block sensor
7-75
Cylinder block sensor
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
2.0 N
·
m (0.20 kgf
·
m, 1.5 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
18 N
·
m (1.8 kgf
·
m, 13 lb
·ft
)
32 N
·
m (3.2 kgf
·
m, 24 lb
·ft
)
32 N
·
m (3.2 kgf
·
m, 24 lb
·ft
)
15 N
·
m (1.5 kgf
·
m, 11 lb
·ft
)
1
2
3
4
5
6
7
7
8
8
6
9
9
10
10
12
12
11
11
New
4
5
New
New
New
13031303
13031303
AA
AA
EE
Part name
Q
’ty
Remarks
1Bolt M6
× 20 mm 1
2Sensor 1
Crankshaft
position
3Sensor 1
Engine tem-
perature
4 Sensor 2 Thermo
5Gasket 2
6Knock sensor 2
7Bolt M6
× 25 mm 8
8 Bracket 2
9 Plug M16
× 11 mm 2
10 O-ring 2
11 Screw M5
× 25 mm 2
12 Anode 2
