Yamaha F400A 2022 - Fuel Filter Assembly

6-3
Fuel filter assembly
Fuel filter assembly
1
11
10
9
5
4
7
3
8
17
14
15
13
21
18
18
19
20
16
12
2
1
New
New
6
EE
5 N
·
m (0.5 kgf
·
m, 3.7 lb
·ft
)
Part name
Q
’ty
Remarks
1Bolt M6
× 16 mm 3
2Cover 1
3 Plastic tie 1
4 Retainer 1
5Bolt M6
× 20 mm 2
6 Grommet holder 1
7 Rigging grommet 1
8 Plastic tie 2
9Hose 1
10 Clamp 1
11 Joint 1
12 Fuel filter assembly 1
13 Cap 1
14 Fuel filter element 1
15 O-ring 1
16 Holder 1
17 Fuel cup assembly 1
18 Bolt M6
× 16 mm 2
19 Holder 1
20 Clamp 1
21 Bracket 1
Part name
Q
’ty
Remarks
