Yamaha F400A 2022 - Drive Shaft and Lower Case (Regular Rotation Model)

8-27
Drive shaft and lower case (regular rotation model)
Drive shaft and lower case (regular rotation model)
GG
572572
LTLT
GG
GG
GG
GG
EPEP
GG
GG
GG
EPEP
EPEP
11
22
21
12
13
14
20
26
27
7
6
New
25
24
23
New
5
18
8
9
10
17
1
3
4
15
3
New
19
New
16
New
2
2
1
New
New
46 N
·
m (4.6 kgf
·
m, 34 lb
·ft
)
240 N
·
m (24 kgf
·
m, 177 lb
·ft
)
175 N
·
m (17.5 kgf
·
m, 129 lb
·ft
)
Part name
Q
’ty
Remarks
1Cover 1
2Bolt M8
× 20 mm 2
3Housing 1
4Ring nut M86 1
5 Spacer 1
6 Pinion nut M18 1
7 Pinion 1
8Drive shaft 1
9 Spacer 1
10 Pinion shim (T3)
—
11 Forward gear 1
12 Thrust bearing 1
13
Forward gear shim
(T1)
1
14 Adapter 1
15 O-ring 1
16 Oil seal 2
17 Nut M35 1
18 Claw washer 1
19 Tapered roller bearing 1
20 Circlip 1
21 Washer 1
22 Tapered roller bearing 1
23 Dowel 1
24 Circlip 1
25 Roller bearing 1
26 Needle bearing 1
27 Lower case 1
Part name
Q
’ty
Remarks
