Propeller shaft housing (regular rotation model)
8-26
b. Bend one of the 4 tabs on the claw
washer outward, and then bend the
other 3 tabs inward.
Ring nut wrench “1”
90890-06932
Ring nut wrench extention 2 “2”
90890-06784
Ring nut wrench extension “2”
YB-06784
Ring nut
1st: 155 N·m (15.5 kgf·m, 114
lb·ft)
2nd: Rotate the drive shaft by
10 turns or more.
3rd: 250 N·m (25 kgf·m, 184
lb·ft)
