System diagram
3-33
(*1). Resistor cap
(*2). Joint connector
A. Main station
B. Joystick station
a. Power port
b. Bus port
c. Device port
17 Autopilot panel 6X9-8253V-01
18 Joystick 6X9-482A0-01
19 Helm unit assembly 6GR-615A0-00
20 Tilt helm unit 6GR-6154A-00
21 Helm unit assembly 6X9-762H0-01
22 BCU 6X9-8591T-33
23 Key fob and receiver assembly
6X9-86254-04
Radio frequency 433 MHz,
Key fob: 2 pcs.
6X9-86254-13
Radio frequency 315 MHz,
Key fob: 2 pcs.
24 Multi-hub 6Y8-81920-01 w/ resistor cap, Gray
25 Main bus wire
6Y8-82553-01 0.3 m (1 ft)
6Y8-82553-50 3.0 m (10 ft)
6Y8-82553-11 4.6 m (15 ft)
6Y8-82553-21 6.1 m (20 ft)
6Y8-82553-31 7.6 m (25 ft)
6Y8-82553-41 9.1 m (30 ft)
26 System power supply wire 6Y8-83553-02 w/ 10 A fuse, 2.4 m (8 ft)
27 Conversion harness 6Y9-83553-00 DEC to hub, 0.3 m (1 ft)
28 Conversion harness 6YM-83553-00 0.9 m (3 ft)
29 CL5 display 6YM-83710-14 No Wi-Fi
30 Tank wire 6YD-8356N-00
31 Fuel tank —
32 Heading sensor 6X9-8A410-01
33 Single (inline) hub 6Y8-81920-11 w/ resistor, 4–6P, White
34 GPS unit 6X9-88107-02
35 Propeller light 6KA-83720-00
36 Extension wire harness
6X9-83553-70 7 m (23 ft)
6X9-83553-80 10 m (32 ft)
37 Aux joystick harness 6X9-82580-G0
38 All start/stop switch 6X9-82570-B1
39 Engine shut-off switch 6X9-82570-D1 Joystick station
Ref.
No.
Part name Part No. Remarks
