System diagram
3-53
(*1). Resistor cap
(*2). Joint connector
A. Main station
B. Sub station
C. Joystick station
a. Power port
b. Bus port
c. Device port
P. Port
C. Center
S. Starboard
The part numbers are subject to change without notice. Make sure to confirm the latest part numbers.
40 EKS harness 6X9-82716-80
41 All start/stop switch 6X9-82570-B1 2nd station/Joystick station
42 Single (inline) hub 6Y8-81920-11 w/ resistor, 4–6P, White
43 GPS unit 6X9-88107-02
44 Extension wire harness
6X9-83553-70 7 m (23 ft)
6X9-83553-80 10 m (32 ft)
45 Aux joystick harness 6X9-82580-G0
46 Engine shut-off switch 6X9-82570-D1 Joystick station
Ref.
No.
Part name Part No. Remarks
To Next Page
