3-60
System diagram
16 Key fob and receiver assembly
6X9-86254-04
Radio frequency 433 MHz,
Key fob: 2 pcs.
6X9-86254-13
Radio frequency 315 MHz,
Key fob: 2 pcs.
17 BCU harness 6X9-82386-20 DEC to Autopilot/Joystick
18 Extension wire harness
6X9-82521-00 4.6 m (15 ft)
6X9-82521-10 9.1 m (30 ft)
19 Autopilot panel 6X9-8253V-01
20 Joystick 6X9-482A0-01
21 Helm unit assembly 6GR-615A0-00
22 Tilt helm unit 6GR-6154A-00
23 Multi-hub 6Y8-81920-01 w/ resistor cap, Gray
24 Main bus wire
6Y8-82553-01 0.3 m (1 ft)
6Y8-82553-50 3.0 m (10 ft)
6Y8-82553-11 4.6 m (15 ft)
6Y8-82553-21 6.1 m (20 ft)
6Y8-82553-31 7.6 m (25 ft)
6Y8-82553-41 9.1 m (30 ft)
25 System power supply wire 6Y8-83553-02 w/ 10 A fuse, 2.4 m (8 ft)
26 Conversion harness 6Y9-83553-10 DEC to hub, 0.3 m (1 ft)
27 Conversion harness 6YM-83553-00 0.9 m (3 ft)
28 CL5 display 6YM-83710-14 No Wi-Fi
29 Tank wire 6YD-8356N-00
30 Fuel tank —
31 Heading sensor 6X9-8A410-01
32 Propeller light 6KA-83720-00
33 2nd helm harness (Center)
6X9-8258A-60 5 m (16 ft)
6X9-8258A-70 8 m (26 ft)
6X9-8258A-80 12 m (38 ft)
34 2nd helm harness (Starboard side)
6X9-8258A-30 5 m (16 ft)
6X9-8258A-40 8 m (26 ft)
6X9-8258A-50 12 m (38 ft)
35 2nd helm harness (Port side)
6X9-8258A-00 5 m (16 ft)
6X9-8258A-10 8 m (26 ft)
6X9-8258A-20 12 m (38 ft)
36 Helm harness (2nd station) 6X9-8258A-B1 0.9 m (3 ft)
37 Digital Electronic Control 6X9-48207-12 2nd station
Ref.
No.
Part name Part No. Remarks
