CL5 display calibration
3-69
4. Check the contents of the display and
proceed to the next step.
5. Turn the steering wheel clockwise until
starboard outboard motor reaches full
STBD lock and the message appears.
Confirm the starboard outboard motor is
at full STBD lock, and then tap “Set”.
• For triple engine applications, after this step,
do the center outboard motor, and then do
the port outboard motor.
• For quad engine applications, after this step,
do the center starboard outboard motor,
then the center port outboard motor, and
then do the port outboard motor.
• For quint engine applications, after this step,
do the C STBD engine, then the CENTER
engine, then the C PORT engine, and then
do the PORT engine.
6. Turn the steering wheel clockwise until the
port outboard motor reaches full STBD
lock and the message appears. Confirm
the port outboard motor is at full STBD
lock, and then tap “Set”.
7. Turn the steering wheel counterclockwise
until the port outboard motor reaches full
PORT lock and the message appears.
Confirm the port outboard motor is at full
PORT lock, and then tap “Set”.
• For triple engine applications, after this step,
do the center outboard motor, and then do
the port outboard motor.
• For quad engine applications, after this step,
do the center port outboard motor, then the
center starboard outboard motor, and then
do the starboard outboard motor.
• For quint engine applications, after this step,
do the C PORT engine, then the CENTER
engine, then the C STBD engine, and then
do the STBD engine.
