Clamp bracket dimensions
1-3
Clamp bracket dimensions
TIP:
The dimension values may include reference values.
21 (0.8)
222 (8.7) 222 (8.7)
163.5 (6.4)
50.8 (2.0)18.5 (0.7)
405 (15.9)24 (0.9)
13 (0.5)
163.5 (6.4)
45 (1.8)
125.4 (4.9) 125.4 (4.9)
92.5 (3.6) 254 (10.0)
mm (in)
