2-21
Bracket unit
Activating and deactivating the PTT TotalTilt™ function
Make sure that all people are clear of the outboard motor when tilting the outboard motor up
and down. Body parts can be crushed between the outboard motor and the clamp bracket
when the outboard motor is trimmed or tilted.
1. Fully tilt the outboard motor down.
2. Remove the clip from the engine shut-off switch.
3. Hold the “DN” (down) side of the PTT switch pushed.
The PTT switch can be used not only on the remote control lever side, but also on the bottom cowling
side.
4. Operate the trim zero set while keeping the “DN” (down) side of the PTT switch pushed.
1. Engine shut-off switch
2. Clip
3. Engine shut-off cord (lanyard)
