10-23
Predelivery check
Shift and throttle op-
eration
Check that the gear shift operates properly when the remote
control lever is moved from the N position to the F or R position.
Not properly → Check the shift actuator and related parts.
8-11
8-18
8-48
9-13
Check that the throttle operates properly when the remote con-
trol lever is moved from the F or R position to the fully open posi-
tion.
Not properly → Check the ETV and/or LPS.
6-29
Outboard motor
mounting height
Check the outboard motor mounting height.
Improper → Adjust.
10-25
PTT unit
Check the PTT unit operation.
Not smooth → Check the PTT fluid level and PTT motor electric
current when the relief valve operate.
10-20
Check that there is no abnormal noise produced when the out-
board motor is tilted up or down.
Abnormal noise → Overhaul PTT unit.
9-45
9-52
9-57
9-62
Steer the tilted-up outboard motor.
Interference → Check the hose and wire harness routing, or
mounting of the outboard motor.
3-13
5-1
1-2
Steering system
Check that the steering operates smoothly.
Not smooth → Check the steering arm, swivel bracket, steering
actuator, helm unit or related parts.
9-32
9-42
Check that the there is no interference with hose or leads when
the outboard motor is steered.
Interference → Check the hose and wire harness routing.
3-13
5-1
Test run
Start the engine, and then check that the gear shift operates
properly.
—
Warm up the engine, and then check the engine idle speed.
Out of specification → Perform the troubleshooting procedures.
10-9
4-25
Operate the boat at trolling speed. —
Operate the outboard motor according to the break-in proce-
dure.
—
Check that the outboard motor does not tilt up when reverse op-
eration.
Tilt up → Check the PTT unit.
9-45
Check that the power trim operates smoothly while cruising.
Not smooth → Check the PTT unit.
9-45
Item Procedures See
