A-25
Shim selection table and chart (regular rotation model)
Pinion shim (T3) selection table
The shim thickness does not have to be adjusted for the blue-colored cells.
A. Pinion distance measurement
B. Shim thickness adjustment
A 0.38 0.39 0.40 0.41 0.42 0.43 0.44 0.45 0.46 0.47 0.48 0.49 0.50 0.51 0.52 0.53 0.54 0.55 0.56 0.57 0.58 0.59 0.60
B +0.37 +0.36 +0.35 +0.34 +0.33 +0.32 +0.31 +0.30 +0.29 +0.28 +0.27 +0.26 +0.25 +0.24 +0.23 +0.22 +0.21 +0.20 +0.19 +0.18 +0.17 +0.16 +0.15
A 0.61 0.62 0.63 0.64 0.65 0.66 0.67 0.68 0.69 0.70 0.71 0.72 0.73 0.74 0.75 0.76 0.77 0.78 0.79 0.80 0.81 0.82 0.83
B +0.14 +0.13 +0.12 +0.11 +0.10 +0.09 +0.08 +0.07 +0.06 +0.05 +0.04 +0.03 +0.02 +0.01 -0.01 -0.02 -0.03 -0.04 -0.05 -0.06 -0.07 -0.08
A 0.84 0.85 0.86 0.87 0.88 0.89 0.90 0.91 0.92 0.93 0.94 0.95 0.96 0.97 0.98 0.99 1.00 1.01 1.02 1.03 1.04 1.05 1.06
B -0.09 -0.10 -0.11 -0.12 -0.13 -0.14 -0.15 -0.16 -0.17 -0.18 -0.19 -0.20 -0.21 -0.22 -0.23 -0.24 -0.25 -0.26 -0.27 -0.28 -0.29 -0.30 -0.31
AA 1.07 1.08 1.09 1.10 1.11 1.12 1.13 1.14 1.15 1.16 1.17 1.18 1.19 1.20 1.21 1.22 1.23 1.24 1.25 1.26 1.27 1.28 1.29
B -0.32
-0.33 -0.34 -0.35 -0.36 -0.37 -0.38 -0.39 -0.40 -0.41 -0.42 -0.43 -0.44 -0.45 -0.46 -0.47 -0.48 -0.49 -0.50 -0.51 -0.52 -0.53 -0.54
A 1.30 1.31 1.32 1.33 1.34 1.35 1.36 1.37 1.38 1.39 1.40 1.41 1.42
B -0.55 -0.56 -0.57 -0.58 -0.59 -0.60 -0.61 -0.62 -0.63 -0.64 -0.65 -0.66 -0.67
(mm)
