section
D 5
72 1098/1098S - M.Y. 2007 - edition 00
Use and maintenance
Connect the pressure sensor (5) to socket (A) or (C) of the cable (3).
Notes
Measure the compression on one cylinder at a time.
On the DDS tester (1), select the “Measurement module” function by pressing the corresponding icon; then press the
“Cylinder Compression” icon (D) followed by the “Start” icon (E).
A
C
3
D
E
