M 2
31098/1098S - M.Y. 2007 - edition 00
Injection - ignition system
2 - Fuel injection-ignition system
The electrical components of the fuel injection-ignition system are listed below: The reference next to each component is that
shown in the diagram in Sect. P 1.
2 Ignition switch
3 Left cooling fan
4 Right cooling fan
5 Starter motor
6 Starter contactor
7 Battery
8 Regulator fuse
9 Regulator
15 Fuel tank
16 Stepper motor
17 Injection relay
18 Self-diagnosis
19 Horizontal cylinder coil
20 Vertical cylinder coil
21 Horizontal cylinder spark plug
22 Vertical cylinder spark plug
23 Horizontal cylinder injector
24 Vertical cylinder injector
25 Throttle position sensor
26 Rpm/timing sensor
27 Coolant temperature sensor
28 Speed sensor
29 Side stand
31 Neutral switch
32 Oil pressure switch
34 ECU
35 Fuses
40 Air temperature sensor
