1331098/1098S - M.Y. 2007 - edition 00
Engine
6.3 - Clutch assembly: primary drive gears
1O-ring
2 Oil seal
3 Primary drive gears
4 Bearing
5 Circlip
6 Bearing
7 Spacer
8 Spacer
9 Spacer
10 Lock washer
11 Nut
12 Circlip
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
8
2
C
1
6
12
11
10
9
D
3
4
5
7
1
