2 GT 1000 - M.Y. 2007 - edition 00
Injection - ignition system
2 - Fuel injection-ignition system 3
3 - System components 4
Electronic Control Unit (ECU) 4
Removal of the battery support 6
Refitting the battery support 9
Electric injector 14
Air pressure sensor 15
Coolant temperature sensor 16
Air temperature sensor 17
Ignition coils 18
Throttle Position Sensor (TPS) 21
Rpm/timing sensor 22
Injection relay 23
CAN Line 24
