Ducati 1098 2007 - 3 - Hydraulic front brake

A
B
C
D
E
F
G
H
L
M
N
P
section
G 3
22 1098/1098S - M.Y. 2007 - edition 00
Wheels - Suspensions - Brakes
3 - Hydraulic front brake
1 Banjo bolt
2 Sealing washer
3 Calipers–master cylinder hose
4Clamp
5 Dust cap
6 Bleed valve
7 Banjo bolt
8 Spacer
9Bolt
10 Right brake caliper
11 Left brake caliper
12 Set of 4 brake pads
13 Brake disc
14 Bolt
15 Front brake hose
16 Washer
17 Rivet
18 Grommet
19 Mudguard
20 Clip
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
13 14
16
17
20
18
19
4
2
11
8
73 97
2
15
2
1
6
5
12
8109
1314
1
