Ducati 1098 2007 - 3 - Seat - seat cowling and side panels

A
B
C
D
E
F
G
H
L
M
N
P
section
E 3
171098/1098S - M.Y. 2007 - edition 00
Fairings
3 - Seat - seat cowling and side panels
1Seat
2Bolt
3Washer
4 Passenger seat
5 Seat cover
6 Dual seat cowling
7Bolt
8Bolt
9 Left side panel
10 Right side panel
11 Bolt
12 Bolt
13 Threaded insert
14 Seat lock
15 Control cable
16 Seat catch
17 Support
18 Nut
19 Seat cowling heat shield
20 Rubber mounting
21 Flange
22 M5 clip
23 M6 clip
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
5
11
10
1
3
2
7
4
8
16
6
15
21
20
23
20
19
13121122
17
181122
9 12
1413
22
1
