section
F 5
26 1098/1098S - M.Y. 2007 - edition 00
Controls - Devices
Refitting the gearchange control
To refit the gearchange control, reverse the operations of the removal procedure.
In particular, grease the O-rings 6), apply threadlocker to the bolt (13), pivot bolt (5) and bolt (17) and then tighten them to the
specified torque (Sect. C 3).
Operation Section reference
Refit the left-hand fairing E 2
2
LOCK
1
LOCK
A
5
13
17
