C 1.1
71098/1098S - M.Y. 2007 - edition 00
Technical data
Front suspension (1098S)
Rear wheel
Rear suspension (1098)
Rear suspension (1098S)
Reference Technical specifications
Type Öhlins: FG315 hydraulic upside-down radially mounted
fork with external adjusters for adjustment of rebound,
compression, and preload (for inner springs of fork legs).
Fork Stanchion diameter: 43 mm
Travel along leg axis: 120 mm.
Hydraulic damping standard setting.
Unscrew the adjuster from fully closed position
(counter clockwise)
compression: 8 clicks
rebound: 10 clicks
Oil capacity per fork leg 155 mm
Reference Standard value Service limit
Minimum tread depth In the most worn part 2 mm
Tyre pressure (Cold) 2.2 bar - 2.4 kg/cm
2
Swingarm pivot shaft runout On 100 mm 0.2 mm
Wheel rim runout Radial 0.8 mm 2 mm
Axial 0.5 mm 2 mm
Chain Make
Type
DID
525 HV 2
Dimensions 5/8" x 5/16"
No. of links 97+1 joining link
Reference Technical specifications
Type Showa: progressive monoshock with adjustable
rebound, compression and spring preload
Shock absorber Travel 59.5 mm
Standard setting compression: 2 turns
rebound: 2 turns
Spring preload 28 mm
Wheel travel 127 mm
Reference Technical specifications
Type Öhlins: progressive monoshock with adjustable
rebound, compression and spring preload
Shock absorber Travel 59.5 mm
Unscrew the adjuster from fully closed
position (clockwise)
compression: 10 clicks
rebound: 10 clicks
Spring preload 23 mm
Wheel travel 127 mm
