24 1098/1098S - M.Y. 2007 - edition 00
Frame
6 - Frame inspection
1 Headlight assembly
2Frame
3Rear subframe
4Bolt
5Bolt
6Nut
7 Headlight
8 Instrument panel
9 Spacer
10 Nut
11 Rubber mounting
12 Bolt
13 Spacer
14 Rubber mounting
15 Air temperature sensor
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
14 1215 13 11
4
1
8
10 11 7 3
6
2
8
9
1
