Ducati 1098 2007 - Stands

A
B
C
D
E
F
G
H
L
M
N
P
section
H 5
20 1098/1098S - M.Y. 2007 - edition 00
Frame
5 - Stands
1 Sidestand
2Bolt
3 Bracket
4Bolt
5 Switch
6 Inner spring
7 Spring assembly
8Plate
9 Pivot bolt
10 Nut
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
3
5
2
1
10 9 8
7
6
4
1
