A
B
C
D
E
F
G
H
L
M
N
P
section
N
2 1098/1098S - M.Y. 2007 - edition 00
Engine
1 - Removal–refitting of the engine assembly 5
Removal of the engine 6
Refitting the engine 9
2.1 - Lubrication system: oil pump 10
Removal of the oil pump 11
Disassembly of the oil pump 12
Reassembly of the oil pump 13
Refitting the oil pump 14
2.2 - Lubrication system: oil cooler 15
Removal of the lubrication system 16
Oil cooler inspection 18
Refitting the lubrication system 18
3.2 - Cooling system: radiator 20
Removal of the radiator 21
Renewal of the cooling fan 23
Refitting the radiator 24
Removal of the cooling system hoses and unions 26
Refitting the cooling system hoses and unions 29
3.3 - Cooling system: water pump 32
Removal of the water pump 33
Refitting the water pump 36
4.1 - Cylinder head assemblies: checks and adjustments 41
Checking and adjusting the valve clearances 42
Checking valve lift 44
Checking the engine timing 46
4.2 - Cylinder head assemblies: timing 49
Removal of the timing belt covers 50
Removal of the tensioner pulley/timing belt 51
Removal of the camshaft pulleys/idler pulley 51
Removal of the tensioner and idler pulley mounting studs 52
Disassembly of the camshaft pulleys 53
Removal of the timing belt driveshaft pulleys 54
Refitting the timing belt driveshaft pulleys 56
Refitting the idler and tensioner pulley mounting studs 58
Reassembly of the timing pulleys 59
Refitting the camshaft pulley/idler pulley 60
Refitting the timing belts 63
Refitting the timing covers 65
4.4 - Cylinder head assemblies: camshafts 66
Removal of the camshafts 67
Checking the camshafts and supports 69
Refitting the camshafts 70
Removal of the intake manifold and coolant union 76
Refitting the intake manifold and coolant union 77
4.5 - Cylinder head assemblies: valves–rocker arms 78
Removal of the cylinder heads 79
Removal of the valves 80
Removal of the valve rocker arms 81
