291098/1098S - M.Y. 2007 - edition 00
Frame
Checking the frame
Check the dimensions of the frame against the dimensions shown here to determine whether it needs to be realigned or
renewed.
Important
Badly damaged frames must be renewed and not repaired. Any work carried out on the frame can give rise to potential danger,
infringing the requirements of EC directives concerning manufacturers' liability and general product safety.
Frame general dimensions (mm)
20,7˚
55
N7
43
152,5
174,5
217,5
316,6
89
205,3
58,8
55
60
191,4
100,3
205,3
155,1
30,3
133,2
77
104,2
102,5 102,5
253,8
157,2
706,7
123,6
22,7
N7
