Ducati 1098 2007 - 8 - Flywheel;alternator

A
B
C
D
E
F
G
H
L
M
N
P
section
N 8
1631098/1098S - M.Y. 2007 - edition 00
Engine
8 - Flywheel/alternator
1Bolt
2 Cylinder coolant inlet union
3 Ignition inspection plug
4 Oil seal
5O-ring
6 Cover
7Bolt
8 Aluminium gasket
9 Cable guide
10 Washer
11 Bolt
12 Bolt
13 Bolt
14 Flange
15 Flanged nut
16 Belleville washer
17 Flywheel
18 Washer
19 Inner ring
20 Needle roller bearing
21 Electric starter driven gear
22 Starter clutch
23 Flywheel-starter clutch assembly
24 Alternator rotor
25 Bolt
26 Bolt
27 Bearing
28 Circlip
29 Left-hand side crankcase cover
30 Locating dowel
31 Bracket
32 Bolt
33 Alternator stator
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
27
25
26
30
2
1
11
10
9
10
13
4
212 8
3
5 6 7
32
31
28
29
14
22
21
20 19
18
17
23
15
16
24 33
23
1
