section
D 5
50 1098/1098S - M.Y. 2007 - edition 00
Use and maintenance
Tester power supply
The DDS tester (1) may be powered in any one of the following ways:
- from the mains power supply by connecting the mains adapter (14) to the power connection socket (N);
- from the motorcycle by connecting the specific cables (see paragraph “Connection to motorcycle”);
- from the tester's internal battery: the battery (Q) is housed in the top part of the tester. To operate the tester (1) using the
internal battery and to recharge the battery, refer to the “User Manual” supplied with the DDS tester.
To switch on the display, press the button (T).
1
N
T
14
Q
