D 4
91098/1098S - M.Y. 2007 - edition 00
Use and maintenance
4 - Maintenance operations
Checking the engine oil level
Check the engine oil level in the sight glass (1) on the right-hand side of the oil sump.
Stop the engine and allow a few minutes for the oil to settle to a steady level.
Check the level with the motorcycle perfectly vertical and with the engine warm (but not running).
The oil must be between the MIN and MAX marks. If the oil level is low, remove the RH half fairing (Sect. E 2) and top up.
Remove the filler plug (2) and top up with the recommended oil.
Refit the filler plug and all previously removed parts.
MAX
MIN
1
2
1
