Refitting the airbox and throttle body
Locate the hose clamps (B) in their seats on the air intakes (C).
Position the airbox (20) and the throttle body (11) on the motorcycle.
Tighten the hose clamps (B) to the specified torque (Sect. C 3).
C
B
C
B
20
11
C
B
B
C
