42 1098/1098S - M.Y. 2007 - edition 00
Wheels - Suspensions - Brakes
Overhauling the rear swingarm
Inside the swingarm (4), at the point at which it pivots on the frame, there are a pair of ball bearing races (19) on the right side
and a pair of roller bearings (25), with seal rings (23), on the left side.
23
25
23
19
19
