Ducati 1098 2007 - 1 - Headlight shell - rear-view mirrors

A
B
C
D
E
F
G
H
L
M
N
P
section
E 1
31098/1098S - M.Y. 2007 - edition 00
Fairings
1 - Headlight shell - rear-view mirrors
1 Headlight shell
2Bolt
3Washer
4Bolt
5Bolt
6 Clip
7Rivet
8 RH rear-view mirror
9 LH rear-view mirror
10 Nut
11 Nylon washer
12 Special screw
13 Windshield
14 Splashguard
15 Upper gasket
16 Lower gasket
17 Threaded insert
18 Bolt
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
1
8
15
10
13
9
A
16
7
6
12
11
4
5
3 2
17
14
18
17
A
16
1
