2 1098/1098S - M.Y. 2007 - edition 00
Controls - Devices
1 - Throttle and choke controls 3
Adjusting the throttle cable 4
Removal of the throttle cable 4
Refitting the throttle twistgrip 5
2 - Hydraulic clutch control 7
Removal of the clutch master cylinder assembly 8
Refitting the clutch master cylinder assembly 9
Removal of the clutch slave cylinder 11
Refitting the clutch slave cylinder 13
3 - Front brake control 16
Removal of the front brake master cylinder 17
Refitting the front brake master cylinder 18
4 - Rear brake control 19
Removal of the complete rear brake control 20
Disassembly of the rear brake master control 21
Refitting the rear brake control 22
5 - Gearchange control 23
Removal of the complete gearchange control 24
Disassembly of the gearchange control 25
Refitting the gearchange control 26
