Frame
Disassembly of structural components and the frame
Before carrying out dimensional checks on the frame, you must remove all the superstructures fitted, referring to the removal
procedures outlined in the sections of this manual.
The structural components of the frame (2) are the headlight assembly (1) and the rear subframe (3).
Both serve to support motorcycle superstructures and must therefore be in perfect condition.
