Ducati 1098 2007 - Steering Damper

A
B
C
D
E
F
G
H
L
M
N
P
section
H 3
14 1098/1098S - M.Y. 2007 - edition 00
Frame
3 - Steering damper (1098)
1 Steering damper
2Bolt
3Bolt
4 Mounting clamp
5Bolt
6 Ball joint
7 Spacer
8O-ring
9 Spacer
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
8
45
9
1
2
3
6
7
1
