68 1098/1098S - M.Y. 2007 - edition 00
Wheels - Suspensions - Brakes
Refitting the rear sprocket
Check the cush drive bushes (12) for signs of wear and, if necessary, remove from the sprocket flange and renew them.
Refitting is the reverse of removal.
If it was necessary to remove the cush drive bushes (12), grease all the mating surfaces and the undersides of the retaining
nuts (10) of the cush drive bushes (12) with the recommended grease.
Check for wear following the instructions given at the beginning of this section.
To refit the nut (8), follow the instructions given for the axle nut in Sect. G 4.
Operation Section reference
Refit the rear wheel G 4
Adjust the chain tension D 4
11
7
13
14
12
10
9
8
B
11
8
7
B
