2 1098/1098S - M.Y. 2007 - edition 00
Fairings
1 - Headlight shell - rear-view mirrors 3
Removal of the rear-view mirrors 4
Refitting the rear-view mirrors 5
Removal of the headlight shell 6
Refitting the headlight shell 8
2 - Fairing panels 11
Removal of the side fairings 12
Removal of the front shield 14
Refitting the front shield 14
Refitting the side fairings 15
3 - Seat - seat cowling and side panels 17
Removal of the seat 18
Removal of the side panels and seat cowling 19
Refitting the side panels and seat cowling 22
Refitting the seats 26
Refitting the pillion seat 27
4 - Front mudguard 28
Removal of the front mudguard 28
Refitting the front mudguard 29
