51098/1098S - M.Y. 2007 - edition 00
Engine
1 - Removal–refitting of the engine assembly
1Bolt
2Nut
3Bolt
4 Swingarm pivot shaft
5Washer
6Washer
Important
Bold reference numbers in this section identify parts not shown in the figures alongside the text. Refer to the exploded view
diagram.
1
2
3
5
4
1
