34 1098/1098S - M.Y. 2007 - edition 00
Frame
Removal of the number plate holder
Undo the bolts (12) and remove the number plate holder cover (2).
Undo the bolts (5) securing the number plate holder (1) to the frame (4).
Disconnect the rear turn signal connectors from the main wiring loom (Sect. P 1) and remove the number plate holder assembly.
12
12
2
5
4
1
