2 1098/1098S - M.Y. 2007 - edition 00
Frame
1 - Handlebars 3
Removal of the handlebars 4
Refitting the handlebars 5
2 - Steering 6
Adjusting the steering head bearings 7
Steering angle adjustment 8
Removal of the steering head components 9
Refitting the steering head components 11
3 - Steering damper (1098) 14
Removal of the steering damper 15
Refitting the steering damper 16
4 - Footrest brackets 17
Removal of the footrests 18
Refitting the footrests 19
5 - Stands 20
Removal of the sidestand. 21
Refitting the sidestand 23
6 - Frame inspection 24
Disassembly of structural components and the frame 25
Checking the frame 29
Reassembly of structural components and the frame 31
7 - Number plate holder 33
Removal of the number plate holder 34
