Disassembly of the gearchange control
Refer to the exploded view at the beginning of this section for indications on disassembly and renewal of gearchange control
components.
If the bush (2) inside the pedal (1) needs replacing, drive the replacement bush into place using a press. The bush must be seated
2 mm below the outer face of the pedal.
Warning
After working on the gearchange control, check the position of the gear pedal.
To adjust the position of the gearchange pedal, follow the instructions given in Sect. D 4.
2 mm2 mm
1
2
