Ducati 1098 2007 - Renewal of the Rear Sprocket

A
B
C
D
E
F
G
H
L
M
N
P
section
G 8
671098/1098S - M.Y. 2007 - edition 00
Wheels - Suspensions - Brakes
Renewal of the rear sprocket
Hold the stub axle against rotation and, using a socket wrench, loosen the nut (8).
Fully unscrew the nut (8) and remove the washer (9) and the flange (11) complete with the rear sprocket (7).
Recover the spacer (14).
Using a mallet, tap the sprocket flange (11) with the cush drive bushes (12) off the sprocket (7).
Operation Section reference
Slacken the chain D 4
Remove the rear wheel G 4
11
8
7
11
7
13
14
12
10
9
8
