N 2.2
18 1098/1098S - M.Y. 2007 - edition 00
Engine
Oil cooler inspection
Make a visual inspection of the oil cooler. Renew the cooler in the presence of damage or leaks.
Refitting the lubrication system
Notes
Before installing the hoses (7), check that the O-rings (6) are installed and lubricate them with engine oil.
Locate the feed and return hoses (7) on the cooler with the plate (8) and tighten the bolt (9) to secure.
7
6
7
6
7
6
6
1
7
9
8
7
