section
D 5
78 1098/1098S - M.Y. 2007 - edition 00
Use and maintenance
Press the “Select vehicle” icon and, on the next screen, press the “Select motorcycle” icon; select the motorcycle model and
confirm, then select the version and confirm.
Press the “Select system” icon to display a list of the bike’s systems that can be analysed.
Select “Engine electronics” and press the “Confirm” icon (B). Next, press the “Self-diagnosis” icon to access the corresponding
function.
The DDS tester will interrogate the electronic control unit and display the parameters analysed with their relative values.
Notes
Make the connections with the motorcycle ignition key in the OFF position.
B
