E 1
10 1098/1098S - M.Y. 2007 - edition 00
Fairings
Refit the bolts (5) (on both sides of the headlight support frame) and the bolt (2) with washer (3) under the light assembly. Tighten
the bolts (5) and (2) to the specified torque (Sect. C 3).
Refit the windshield (14) and tighten the bolts (18) to the specified torque (Sect. C 3).
Refit the rear-view mirrors as described above.
Operation Section reference
Refit the side fairings E 2
5
2
3
14
18
