G 1
4 1098/1098S - M.Y. 2007 - edition 00
Wheels - Suspensions - Brakes
Removal of the front wheel
Remove the front brake calipers complete with hoses by undoing the bolts (A).
Warning
Do not operate the brake lever when the calipers are removed. This could cause the brake pistons to be expelled from their bores.
Support the bike so that the front wheel is raised from the ground.
Loosen and remove the nut (1) on left side of the axle.
Recover the washer (2).
A
A
1
2
